• HIGH PERFORMANCE
      LUSTRE* SOLUTIONS
    • PARALLEL FILE SYSTEM

Data-intensive workflows in Research, Government, Energy and Earth Sciences are driving analytics and modeling to extreme levels of fidelity in areas like materials modeling, ignition, brain mapping, climate studies, forecasting and more.

Exponential growth in data inputs is required to fuel every significant step taken to close the gap between a model and the physical world. This data growth profile puts storage infrastructure squarely in the critical path – driving requirements for extreme, dependable performance that scales.

Developed to overcome the toughest storage and data management challenges in extreme, data-intensive environments, DDN EXAScaler appliances scale up and/or out, leveraging a SSD-accelerated, hyper-converged, parallel architecture to deliver industry-leading performance and efficiency for HPC Big Data workflows.

EXTREME PERFORMANCE AND SCALE, NEW TECHNOLOGIES AND OPEN SOURCE

Researchers are the most demanding user community in HPC. To boost research productivity, advanced high performance sites are moving to centralized storage models. A centralized storage approach allows them to provide data access speeds to feed more concurrent projects at higher data rates, incorporate best-of-breed open source and new technology wherever possible, and improve cost-effectiveness and management overhead. A primary requirement when building centralized storage infrastructure is the power to grow to support site-wide data needs, even over multiple clusters or generations of clusters.

DDN EXAScaler – THE INDUSTRY’S MOST ADVANCED LUSTRE APPLIANCE

DDN builds on the experience of over a decade of Lustre development, system design, implementation and support to deliver the EXAScaler line of Lustre appliances. EXAScaler combines the industry’s most powerful storage architecture with the leading Lustre distribution, DDN integration tools, system monitoring tools and deep bench of Lustre experts across engineering, pre-sales and support. The result is the industry’s fastest, most advanced Lustre appliance, proven in the most demanding environments in HPC.

DDN ENTERPRISE LUSTRE DISTRIBUTION
DDN has been working with the core Lustre development team and delivering Lustre solutions for 15 years. To provide our end users with the best Lustre experience bar none, we build EXAScaler Enterprise Lustre Distribution on top of the supported community branch, hardening it for months through extensive automated testing to enhance stability, uptime, and performance.  EXAScaler comes with a time-proven and tested approach to high availability in Lustre, and with an extensive set of tools that simplify deployment, maintenance, and support.

DDN is a very active member of the Lustre community and has contributed many performance, scalability and management features including development or lead test owner on all major features in the recent Lustre 2.9 release.  DDN contributes all core Lustre enhancements to the community and has never forked Lustre.  Because we can incorporate them in our own release faster, DDN developed features are often available to DDN customers exclusively for a period of time before they are incorporated into the main branch.

Lustre-mls-in-page-banner
Security Enhancements and Multi Level Security for High Performance Lustre File System Environments
Product Manager Carlos Aoki Thomas presents Security Enhancements and Multi Level Security for High Performance Lustre File System Environments at SC16

USE CASES

EXAScaler Configurations & Specifications

EXAScaler is factory built-to-order parallel file system and arrives to your data center, tuned, optimized and ready to deploy. Below you will find more information on the components that make-up the solution and allow for flexibility in configuration. Our team of Sales Engineers and Solution Architects will work with you to create the exact configuration that meets your environment’s unique performance, capacity and business requirements.

EXPLORE MODELS: MEET THE UNDERLYING STORAGE SYSTEMS

ES7KX®

  • World’s fastest entry-level Lustre* solution delivers easy migration to parallel file systems
  • Performance: Up to 12GB/sper base enclosure
  • Capacity: Base building block configuration of up to 144 drives in 8U
  • Scale: Scale Up with up to 5PB per rack, capable of spanning multiple racks and Scale out with up to 60 GB/s per rack, capable of spanning multiple racks
ES7K Data Sheet

ES12KX®

  • Enterprise Parallel File System with NAS and Cloud Extensions
  • Performance: Up to 20GB/s per ES12KX System (read & write), aggregated performance up to 100s of GB/sec and 100,000s of file operations
  • Capacity: Up to 16.8PB usable capacity per ES12KX
  • Scale: Add additional ES12K systems to the network for automatic storage and performance scaling
ES12K® Appliance

ES14KX®

  • The world’s most advanced Lustre appliance
  • Performance: Up to 50GB/s per Base Enclosure
  • Capacity: Up to 17.5PB of capacity in just 2 racks
  • Scale: Start under 100 TB and scale to 100s of PB
EXAScaler Product Family Datasheet

EXTERNAL SERVER

  • Power of the Lustre File System in a flexible configuration of 1U servers
  • SFA7700X Appliance base configurations starting at 6 GB/s and 240 TB
  • SFA12KX® Appliance based configurations support over 1TB/s and dozens of Petabytes
  • Performance for mixed workloads up to 1.7M IOPS and 48GB/s bandwidth
  • Up to 228 drives in 12U with two SS8460 Enclosures
  • Up to 180 drives in 12U with two SS8000 Enclosures

SPECIFICATIONS

ES7KX® ES12KX® ES14KX™

PROTOCOLS

Linux and Windows Parallel FS Clients

LUSTRE

IEEL 2.4 based on Lustre 2.5
IEEL 3.0 based on Lustre 2.7*

PERFORMANCE

Up to 20GB/s per Base Enclosure Up to 20GB/s per Base Enclosure Up to 50GB/s per Base Enclosure

METADATA

DDN supports embedded metadata server, or external scale-out metadata server using Lustre DNE

STORAGE HOST PORTS

4x 10/40 GbE
4x InfiniBand™ FDR
16x 10/40 GbE
16x InfiniBand™ FDR
8x InfiniBand™ EDR/FDR
8x 10/40/100GbE
4x Intel® Omni-Path

DRIVE SUPPORT

SSD, Performance SAS and Capacity SAS/
SATA drives, 3.5” 60 in base unit, 396 with expansion enclosures
Supported Drive Types: NL SAS or SSD;
Supported Drive Sizes: LFF 3.5” and SFF 2.5”: 0 in base unit, 1,680 with expansion
Supported Drive Types: NL SAS or SSD;
Supported Drive Sizes: LFF 3.5” and SFF 2.5”: 72 in base unit, 1,752 with expansion enclosures

FILE SERVERS PER BASE ENCLOSURE

2 OSSs 4 OSSs 4 OSSs

SUPPORTED RAID LEVELS

RAID 1/5/6

REPLICATION

Asynchronous using WOS Bridge

DATA AND SYSTEM MANAGEMENT

Quotas (users and groups)
DirectMon Centralized configuration and monitoring solution
Optional EXAScaler Bridge Migrates data across EXAScaler and WOS Object storage for active archive & cloud collaboration
Optional DDN® DataMigrator for automatic data migration form any file system to any storage device
Optional DDN ArchiveDirector™ for Policy-based tiered storage and data migration with mirroring, replication, encryption
CUSTOM CONFIGURATIONS Custom configurations of EXAScaler are available with external OSSs
  • DDN has long been a partner of choice for organizations that need to scale far beyond conventional file system limits. DDN continues to reaffirm its position at the vanguard of the scalable systems marketplace, and therefore as one of the storage leaders of the contemporary Big Data era.
    Mark Peters, Senior Analyst, Enterprise Strategy Group

RESOLVING BIG DATA CHALLENGES

Our SFA Architecture is designed to scale over 1TB/s and support 10/s of petabytes of storage capacity in a
compact and energy efficient data center footprint
